Key Specifications
Power & Speed Ratings
Rated output at six speeds — select the rating that matches your application.
Max. torque: 44 N·m. Please confirm the rating and torque curve required for your specific application before ordering.
Applications
The F1L511 engine is used in the following equipment categories.
01 Construction Machinery — Power source for compact construction equipment.
02 Generator Sets — Suited to 1500 / 1800 rpm generator set applications.
03 Mining Equipment — Air-cooled configuration for mining-site machinery.
04 Water Pumps — Drive unit for pump sets.
05 Trucks — Auxiliary / on-board power for truck applications.
Quality Control & Certification
Quality Control: CE
Certification: ISO9001:2000
Frequently Asked Questions
What is the rated power of the Deutz F1L511? 5.7, 7.3, 8.2, 9.7, 10.5 and 10.9 kW (7.7, 9.9, 11.1, 13.2, 14.3 and 14.8 hp) at 1500, 1800, 2000, 2500, 2800 and 3000 rpm. Maximum torque is 44 N·m.
Is the F1L511 air-cooled or water-cooled? It is air-cooled, with direct injection and natural intake.
What equipment is this engine used for? Construction machinery, generator sets, mining equipment, water pumps and trucks.
What is the engine size and weight? 0.83 L displacement, 100 / 105 mm bore and stroke, 1-cylinder in-line. Net weight 110 kg, weight 190 kg, overall dimension 60 × 75 × 99 cm. Dimension references A / B / C are 392 / 525 / 671 mm.
What warranty do you offer? 12 months / 1000 hours. Product issues are supported with guidance through online and video service.
Which payment methods do you accept? T/T, Western Union and Alibaba online payment.
Is the engine tested before shipment? Yes. The engines have been rigorously tested.
How do I get an accurate price? The price varies based on configuration, serial number and part quality. Send us your engine serial number or a nameplate photo and we will quote the exact configuration you need. HS code: 8408909290.
