For project managers sourcing engines for US-bound gensets or coastal auxiliary vessels, the Deutz BF6M1013C offers a rare combination of mechanical simplicity and EPA Tier 2 certification – a pairing that simplifies both import clearance and field service. Our China-based facility specializes in delivering this 7.14-liter platform with verified emissions documentation, matching the original Bosch injection timing and turbocharger A/R ratios to preserve the certified 218HP output at 1800 RPM for 60Hz applications . Beyond power generation, this engine’s wide torque reserve supports mining dump trucks and terminal equipment where sustained loads demand thermal stability; the charge-air cooling system maintains consistent intake density even in high-ambient-temperature environments . We supply dressed units complete with gear-driven water pump, twin thermostats, and pre-set valve lash – ready for installation with standard SAE hardware. For each outgoing BF6M1013C, we provide a dimensional checklist and torque sequence chart, bridging your workshop standards with our production traceability, no proprietary diagnostic tools required.
Production specification
BF6M1013C | A | B | C | |
mm | 1158 | 760 | 845 | |
Cyl No. and Arrangement | 6-Cyl in-line | |||
Bore/Stroke(mm) | 108/130 | |||
Air-intake way | Turbo charged cooling | |||
Combustion system | Direct injection | |||
Cooling way | Water-cooled | |||
Displacement(L) | 7.14 | |||
Max.Torque(N.m) | 847 | |||
Power(kw) | 170 | |||
Power(hp) | 228 | |||
Speed(rpm) | 2300 | |||
Net Weight(kg) | 572 | |||
Weight(kg) | 650 | |||
Dimension(L*W*H/cm) | 156*95*123 | |||
HS code: | 8408909390 | |||
Application: | construction machinery / generator set / mining equiment / water pump / truck | |||
Certification | ISO9001:2000 | |||
Warranty | 12 Months / 1000 Hours | |||
Quality Control | The engines have been rigorously tested | |||
Payment | T/T, Western Union, Alibaba online payment. | |||
Service | Guidance on product issues through online and video support | |||
The price varies based on configu-ration, serial number, and part quality. For an accurate quote, contact a supplier with your specific engine serial number ornameplate. | ||||
