DEUTZ BF6M1013FC Diesel Engine – 1013FC Flywheel Housing Specs

DEUTZ BF6M1013FC Diesel Engine – 1013FC Flywheel Housing Specs | China Source

We stock the DEUTZ BF6M1013FC as a stripped long block for customers who prefer to reuse their existing injection pump and manifolds. Key differentiators from the EC variant: an 8-bolt crankshaft flange instead of 10-bolt, and a thermostat housing rotated 15 degrees for skid steer clearance. Each engine is compression-tested at our Ningbo warehouse before dispatch. No reconditioned parts used — only new liners and piston rings sourced from Chinese ISO 9001 foundries.

Production specification

BF6M1013FC		A		B		C
	mm	1162		683		990
Cyl No. and Arrangement	6-Cyl in-line
Bore/Stroke(mm)	108/130
Air-intake way	Turbo charged cooling
Combustion system	Direct injection
Cooling way	Water-cooled
Displacement(L)	7.14
Max.Torque(N.m)	1050
Power(kw)	166		186		223
Power(hp)	223		249		299
Speed(rpm)	1500		1800		2300
Net Weight(kg)	572
Weight(kg)	650
Dimension(LWH/cm)	15684123
HS code:	8408909390
Application:	construction machinery / generator set / mining equiment / water pump / truck
Certification	ISO9001:2000
Warranty	12 Months / 1000 Hours
Quality Control	The engines have been rigorously tested
Payment	T/T, Western Union, Alibaba online payment.
Service	Guidance on product issues through online and video support
The price varies based on configu-ration, serial number, and part quality. For an accurate quote, contact a supplier with your specific engine serial number ornameplate.
